High Reliability, High Durability (Laser Welding, IndustrialGrade Fully Sealed Process)
High-Current Pulse Discharge Capability (Maximum Pulse Discharge Current Up to 10A)
High Power and Energy
Low Self-Discharge Rate (Annual Self-Discharge Rate ≤ 3%
Extraordinary Standby Battery Life (Up to 10 Years)
Wide Temperature Operating Range (-40°C to +85°C)
High Reliability
High Durability
High-Current Pulse Discharge Capability
High Power and Energy
Low Self-Discharge Rate
Extraordinary Standby Battery Life
Wide Temperature Operating Range
Capacity when the battery is discharged from 0.25A to 2.0V at 23±2°C | Nominal Capacity | 500 mAh |
Nominal Voltage | 3.7 V | |
Charging Cut-off Voltage | 4.2V | |
Cycle life | ≥500 | |
Maximum Continuous Discharge Current | 2.0A | |
Maximum Pulse Discharge Current | 5.0A | |
Maximum Charging Current | 500mA | |
Internal Resistance (1kHz@RT) | ≤100 mΩ | |
Storage Environment (Recommended) | 10~25 ℃ ≤75% RH | |
Operating Temperature | -40℃~+85℃ (Suitable for –40°C~+85°C wide temperature range applications.) When the operating temperature range exceeds –40°C~+85°C, please contact HCB) |
eCall on-board emergency call system
TCU/T-Box telematics control unit
Portable medical equipment
Smart metering
RF systems
Smart sensors
Security system
